HIWIN MGN-12-C-Z0-H-M Block


  • Series: MG Series
  • Width Type: N (Narrow)
  • Block Type: Square Type
  • Model Size: 12 mm
  • Load Type: C (Standard)
  • Block Mounting Type: Mounting from Top
  • Preload Code: Z0 (Very Light Preload)
  • Precision Code: H (High)
  • Material: M (Stainless Steel)

21 in stock (can be backordered)

The MGN-12-C-Z0-H-M in Brief

The HIWIN part number MGN-12-C-Z0-H-M is a MG Series, Narrow version (MGN), Linear Guide Block. The MGN-12-C-Z0-H-M is compatible with 12 mm MG Series (Narrow version) Guide Rail. It is suitable for miniature applications and very light load duty. It has a standard form square type mounting surface that can accept mounting bolts through the top of the mounting surface. To help maintain precision for many industrial applications, the MGN-12-C-Z0-H-M has a very light preload and high-level precision grade (in relation to other MG Series blocks).

MG Series – Miniature Linear Guideway

Features of MGN Series

Design features of narrow type miniature guideways- MGN:

  1. Tiny and light weight, suitable for miniature equipment.
  2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
  3. Specification with ball retainers would avoid ball falling when the blocks are removed from rails.
  4. Interchangeable types are available in certain sizes and precision grades.

MGN Series Application Examples

  • Printer
  • Robotics
  • Precision Measuring Equipment
  • Semiconductor Equipment
