HIWIN MGW-15-C-Z0-H-M Block

$76.00

HIWIN
  • Series: MG Series
  • Width Type: W (Wide)
  • Block Type: Square Type
  • Model Size: 15 mm
  • Load Type: C (Standard)
  • Block Mounting Type: Mounting from Top
  • Preload Code: Z0 (Very Light Preload)
  • Precision Code: H (High)
  • Material: M (Stainless Steel)

18 in stock (can be backordered)

The MGW-15-C-Z0-H-M in Brief

The HIWIN part number MGW-15-C-Z0-H-M is a MG Series, Wide version (MGW), Linear Guide Block. The MGW-15-C-Z0-H-M is compatible with 15 mm MG Series (Wide version) Guide Rail. It is suitable for miniature applications and very light load duty. It has a standard form square type mounting surface that can accept mounting bolts through the top of the mounting surface. To help maintain precision for many industrial applications, the MGW-15-C-Z0-H-M has a very light preload and high-level precision grade (in relation to other MG Series blocks).

MG Series – Miniature Linear Guideway

Features of MGW Series

Design features of wide type miniature guideways- MGW:

  1. The enlarged width design increases the capacity of moment loading.
  2. Gothic arch contact design has high rigidity characteristics in all directions.
  3. Specification with ball retainers would avoid ball falling when the blocks are removed from rails.
  4. Interchangeable types are available in certain sizes and precision grades.

MGW Series Application Examples

  • Printer
  • Robotics
  • Precision Measuring Equipment
  • Semiconductor Equipment

About STOVIL

STOVIL is an authorized HIWIN distributor and carries the full line of HIWIN’s HG Series, EG Series, WE Series, RG Series, MG Series, QH Series, QE Series, QW Series, and QR Series Linear Guideway products. STOVIL maintains a large and diverse stock of HIWIN Linear Guideway rail, block, and accessory maintenance kits at our facility in Kennesaw, GA. Our HIWIN Linear Guide Rail product offerings are constantly improving to better accommodate the various needs of our customers including standard lengths of each rail profile and configurators that allow cut-to-order custom rail service.

STOVIL has a large line card tailored to the Industrial Automation market. STOVIL carries many of the top brands in product lines such as: Linear Guideways, Actuators, Ball Screws, Motion Control, Safety Products, Miscellaneous Electrical, Cabinets & Enclosures, Maintenance, Robotics, Servo Motors & Drives, Couplers, VFDs, HMIs & PLCs, Gearboxes, Feedback Devices, and Stepper Motors & Drives. These brands include (but are not limited to): Yaskawa, RTA, Brother, SANYO DENKI, Hitachi, Wieland, Häwa/Haewa, ESA Automation, American Control Electronics, Atlanta Drive Systems, HIWIN, Neugart, Rollon, CGI, Bishop Wisecarver, EDrive, R+W Coupling Technology, Tsubaki, Kabel Schlepp, Nadella, Nexen, Schneeberger, and Exlar. STOVIL is always looking for new partnerships to better serve our customers.

Additional information

Shipping Weight 5.573287 oz
Shipping Dimensions 3.783 × 2.73 × 0.663 in
Series

Enlarged Width

Yes

Model Size (mm)

15

Block Type

C, Square Type, Standard

Block Mounting

Top

Preload Class

Very Light Preload, Very Light Preload (~ 0C), Z0

Precision Code

H, High

Material

Stainless Steel
