Actuators

Name Thumbnail Short Description Add to Cart
HIWIN LAM Series - LAM1, LAM2, & LAM3
  • Screw types: Ballscrew / ACME
  • Protection: IP54
  • LAM1 series is compatible with LAK2 / LAK2LR / LAK2D / LAK2BN / LAK2J / LAK6B
  • LAM2 & LAM3 series are compatible with all controllers
  • Working temp: +5°C - 40°C
  • Stroke length: 100mm - 200 mm
HIWIN LAI Series - LAI1 & LAI2
  • Screw types: Ballscrew / ACME
  • Protection: IP20
  • LAI1 series is compatible with LAK2 / LAK2LR / LAK2BN / LAK2J / LAK2D / LAK6B
  • LAI2 series is complatible with all controllers
  • Working temp: +5°C - 40°C
  • Stroke length: 200mm - 300 mm
HIWIN LAS Series - LAS1, LAS2, LAS3, LAS4, & LAS5
  • Screw types: ACME
  • Protection: IP54
  • LAS5 series is compatible with LAK2 / LAK2BN / LAK6B
  • LAS1, LAS2, LAS3, & LAS4 series are compatible with all controllers
  • Working temp: +5°C - 40°C
  • Stroke length: 100mm - 200 mm
HIWIN LAN Series - LAN1, LAN3, LAN3A, LAS4, & LAS5
  • Screw types: ACME
  • Protection: IP540
  • LAN1 series are compatible with all controllers
  • LAN3 and LAN3A series are compatible with LAK6B / LAK2J
  • LAN4 series is compatible with LAK2 / LAK2LR / LAK2D / LAK2BN / LAK2J / LAK6B
  • LAN5 series are compatible with all controllers
  • Working temp: +5°C - 40°C
  • Stroke length: 200mm
HIWIN LAC Series
  • Screw types: ACME
  • Protection: IP54
  • Compatible with all controllers
  • Working temp: +5°C - 40°C
  • Stroke length: 400mm
Rollon Eco System

Eco System's products have been designed to fit in applications where quality movement is needed at a low price. The patented design offers a well-protected, smooth slide that is easily and quickly mounted.

Eco System combines the quality associated with all of ROLLON's products with the affordability needed in application sectors like industrial protective panels, vehicle slides, and machine tool doors.

Eco System is the answer to labor intensive, homemade solutions, cheap bent steel slides, or expensive, overdesigned round or profiled shafting.

The products were designed to keep damaging dirt and particles out. The contact between the rollers and the raceways occurs inside the specially shaped profile, protected from accidental impacts and from debris and impurities.

Rollon Uniline System

The Uniline System is a belt driven actuator with compact rail bearings. The A75 Uniline offers a 275"/sec. high speed and over 20 ft. long stroke design for a wide range of applications. The A75 offers load capacities of up to 1233lbs. in radial direction a and moments of up to 1849 in-lbs. in Mz direction is prefect for applications where economics play a large factor and long strokes work against most actuators. The high speed performance do not jeopardous noise, 72DBA are very quite for this fast moving system. Its large TLV43 Compact Rail system is constructed of large radial bearings that operate on a hardened steel surface and have the ability to operate in contaminated environments. The rail is placed flat against the inside bottom of the extrusion to minimize the overall dimension 2.9" x 2.9".

EDrive E-TAC ET
  • Velocity to 33 in/sec
  • Sealed Chamber Design with Purge Provisions
  • Adjustable Limit Switch Positions
  • Accepts Any Motor up to 3" Square
EDrive VECTAC VT
  • Force From 400 to 2,000 lbs
  • Strokes to 30 inches maximum
  • Velocity to 40 in/sec
  • Sealed Chamber Design with Purge Provisions
  • Adjustable Limit Switch Positions
  • Accepts Any Motor
  • P/N INFO
EDrive L-TAC LS
  • Force From 400 to 2,000 lbs
  • Strokes to 48 inches maximum
  • Velocity to 40 in/sec
  • Sealed Chamber Design with Purge Provisions
  • Adjustable Limit Switch Positions
  • Accepts Any Motor
  • P/N INFO
EDrive Eliminator HD
  • 2,000-25,000 lbs Force
  • Heavy Wall Steel Construction
  • Longest Life
  • Simultaneous High Thrust with High Speed
  • Piston with Rugged Anti Rotation Feature
  • P/N INFO
EDrive Eliminator HDL with Integral Load Cell Option
  • Integrated force measurement
  • 2,000-25,000 lbs Force
  • Accurate within ½ percent of rated force
  • Conforms to latest standard ASTM E4 for
  • Testing Machines
  • Internal load cell – wire connections are "out of the way"
  • Load cell rated for 100 million cycles
  • P/N INFO
EDrive Eliminator HDR with Roller Screw Option
  • 4,000-25,000 lbs Force
  • Heavy Wall Steel Construction
  • Longest Life
  • Simultaneous High Thrust with High Speed
EDrive Eliminator SD
  • 30,000-66,000 lbs Force
  • Heavy Wall Steel Construction
  • Highest (B10) Life Rating
  • Piston with Rugged Anti Rotation Feature
  • Adjustable Limit Switch Positions
  • P/N INFO
EDrive MT Precision
  • Machine Tool Grade
  • High Precision with Force to 15,000 lbs
  • Rugged Steel Construction
  • Designed for High System Stiffness
EDrive EA Series
  • Part of the Legacy Product Line
  • High Precision with Force to 15,000 lbs
  • Rugged Steel Construction
  • Modified or Custom Built
  • Designed for High System Stiffness
EDrive Slides
  • Part of the Legacy Product Line
  • Single & Multi-Axes
  • Rugged Ductile Iron Slide
  • Hardened and Ground Steel Ways
EDrive Limit Switches
  • Part of the Legacy Product Line
  • Linear & Rotary
  • Hermetically Sealed to IP67 Standards
Exlar TRITEX IIâ„¢ AC Rotary Actuator

The Exlar Tritex II AC rotary actuator sets a new benchmark for high performance and small size. These rotary actuators fully integrate an AC powered servo drive, digital position controller, and brushless motor in a compact, sealed package. By combining the latest electronic power technology with advanced thermal management modeling, these rotary actuators are programmable, powerful and precise. They offer a superior solution for applications that can benefit from a compact and fully integrated device.

  • Fully Integrated Drive/Motor
  • Output torque up to 4,696 lbf-in (530 Nm)
  • Speeds up to 4000 rpm
  • Voltage ratings from 100 - 240 VRMS
  • Eliminates costly, high-maintenance servo cables
  • Optional internal gear reducer
  • P/N INFO
Exlar TRITEX IIâ„¢ AC Linear Actuator

By combining the latest electronic power technology with advanced thermal management modeling technology, Exlar has set a new benchmark for performance and size. Tritex II Series actuators integrate an AC powered servo drive, digital position controller, brushless motor and linear actuator in a compact, sealed package. Now you can precisely control motion and solve all of your application requirements with a single, fully integrated device. Simply connect AC power, I/O and communications; and it’s ready to go!

    • Fully Integrated Drive/Motor/Actuator
    • Continuous force up to 3,225 lbf (14 kN)
    • Speeds up to 33 in/s (800 mm/s)
    • Voltage ratings from 100 - 240 VRMS
    • Eliminates costly, high-maintenance servo cables
    • Complete stand-alone solution
    • P/N INFO
Exlar TRITEX IIâ„¢ DC Rotary Actuator

The Tritex II DC powered rotary actuator houses a servo drive, digital positioner and servo motor in a single, compact package. These advanced actuators offer the highest power density and smallest footprint servo driven devices on the market. Their small size and innovative design make it easy to incorporate a fully electronic solution in the space of your existing hydraulic or pneumatic cylinder. Now you can precisely control motion and solve your application requirements with a single, fully integrated device.

  • Fully Integrated Drive/Motor
  • Output torque up to 2078 lbf-in (235 Nm)
  • Speeds up to 5000 rpm per gear ratio
  • Gear ratios up to 100:1
  • Voltage ratings from 12 to 48 VDC
  • Complete stand-alone solution
  • P/N INFO
Exlar TRITEX IIâ„¢ DC Linear Actuator

The Exlar Tritex II DC powered rotary actuator houses a servo drive, digital positioner and servo motor in a single, compact package. These advanced actuators offer the highest power density and smallest footprint servo driven devices on the market. Their small size and innovative design make it easy to incorporate a fully electronic solution in the space of your existing hydraulic or pneumatic cylinder. Now you can precisely control motion and solve your application requirements with a single, fully integrated device.

  • Fully Integrated Drive/Motor/Actuator
  • Continuous force up to 872 lbf (3879 N)
  • Speeds up to 33.3 in/s (846 mm/s)
  • Strokes from 3 to 18 in (75 to 450 mm)
  • Voltage ratings from 100 to 240 VRMS
  • Complete stand-alone solution
  • P/N INFO
Exlar GSX Series Integrated Motor Actuator

Exlar's GSX Series integrated motor actuators integrate all the advantages of Exlar® roller screw and T-LAM stator technologies to create powerful and robust solutions with long life. The specially designed roller screw mechanism efficiently converts electric motor power into linear motion. Planetary rollers, assembled around the extending rod, follow threads that are precisely machined on the inside of the actuator’s hollow rotor.

  • Integrated Motor Actuator
  • Continuous force up to 11,528 lbf (51 kN)
  • Speeds up to 37.5 in/s (952 mm/s)
  • Strokes from 3 to 18 in (75 to 450 mm)
  • ​Voltage ratings from 115 - 460 VRMS and 24 - 48 VDC
  • Compact size
  • Class 1, Division 2 options available
  • P/N INFO
Exlar GSM Series Electric Linear Actuator

Exlar's GSM Series electric linear actuators are a superior and cost effective alternative to traditional electric, hydraulic and ball screw systems. The compact design is the culmination of advanced roller screw technology and an integral brushless servo motor. This robust electric linear actuator is ideal for a variety of medium- to high-performance applications. With GSM actuators, everything from food and beverage packaging, to multi-axis turning centers, to aircraft assembly can be done cleaner, faster, and more accurately and efficiently.

  • Electric Linear Actuator
  • Continuous force up to 3,457 lbf (15 kN)
  • Speeds up to 37.5 in/s (952 mm/s)
  • Strokes from 3 to 18 in (75 to 450 mm)
  • Voltage ratings from 115 - 460 VRMS and 24 - 48 VDC
  • Compact size
  • Class 1, Division 2 options available
  • P/N INFO
Exlar K Series Electric Linear Actuator

The K Series actuators from Exlar provide a truly universal solution for a multitude of rod-style actuator applications. Now available in 60, 75, and 90 mm frame sizes. Two grades of planetary roller screws give you flexibility to select the configuration that is best suited for your application and budget.

  • Electric Linear Actuator
  • Maximum force up to 3,500 lbf (15 kN)
  • Speeds up to 32.8 in/s (833 mm/s)
  • Strokes from 0.7 to 48 in (20 to 1219 mm)
  • Universal solution for rod-style actuation
  • Multiple models and sizes with advanced roller screw
  • P/N INFO
