HIWIN EGH-30-CA-Z0-C Block

HIWIN
  • Series: EG Series
  • Block Type: H (Square Type)
  • Model Size: 30 mm
  • Load Type: C (Heavy Load)
  • Block Mounting Type: A (Mounting from Top)
  • Preload Code: Z0 (Very Light Preload)
  • Precision Code: C (Normal)

8 in stock (can be backordered)

  • HIWIN EG-30-KK Dust Proof Accessory Kit + $40.00
  • Have STOVIL install the add-on kit for you.

The EGH-30-CA-Z0-C in Brief

The HIWIN part number EGH-30-CA-Z0-C is a EG Series Linear Guide Block. The EGH-30-CA-Z0-C is compatible with 30 mm EG Series Guide Rail. It is suitable for heavy load duty and has a square type mounting surface that can accept mounting bolts through the top of the mounting surface. To help maintain precision for many industrial applications, the EGH-30-CA-Z0-C has a very light preload and normal-level precision grade (in relation to other EG Series blocks).

EG Series – Low Profile Ball Type Linear Guideway

Features of EG Series

The design of the EG series offers a low profile, high load capacity, and high rigidity. It also features an equal load rating in all four directions and self-aligning capability to absorb installation-error, allowing for higher accuracies. Additionally, the lower assembly height and the shorter length make the EG series more suitable for high-speed, automation machines and applications where space is limited.

The retainer is designed to hold the balls in the block even when it is removed from the rail.

EG Series Application Examples

  • Automation Devices
  • High-Speed Transportation Equipment
  • Precision Measuring Equipment
  • Semiconductor Manufacturing Equipment

About STOVIL

STOVIL is an authorized HIWIN distributor and carries the full line of HIWIN’s HG Series, EG Series, WE Series, RG Series, MG Series, QH Series, QE Series, QW Series, and QR Series Linear Guideway products. STOVIL maintains a large and diverse stock of HIWIN Linear Guideway rail, block, and accessory maintenance kits at our facility in Kennesaw, GA. Our HIWIN Linear Guide Rail product offerings are constantly improving to better accommodate the various needs of our customers including standard lengths of each rail profile and configurators that allow cut-to-order custom rail service.

STOVIL has a large line card tailored to the Industrial Automation market. STOVIL carries many of the top brands in product lines such as: Linear Guideways, Actuators, Ball Screws, Motion Control, Safety Products, Miscellaneous Electrical, Cabinets & Enclosures, Maintenance, Robotics, Servo Motors & Drives, Couplers, VFDs, HMIs & PLCs, Gearboxes, Feedback Devices, and Stepper Motors & Drives. These brands include (but are not limited to): Yaskawa, RTA, Brother, SANYO DENKI, Hitachi, Wieland, Häwa/Haewa, ESA Automation, American Control Electronics, Atlanta Drive Systems, HIWIN, Neugart, Rollon, CGI, Bishop Wisecarver, EDrive, R+W Coupling Technology, Tsubaki, Kabel Schlepp, Nadella, Nexen, Schneeberger, and Exlar. STOVIL is always looking for new partnerships to better serve our customers.

Additional information

Shipping Weight 30.194515 oz
Shipping Dimensions 4.875 × 3.003 × 1.95 in
Series

Block Type

H, Square Type

Model Size (mm)

30

Load Type

Heavy Load

Block Mounting

Mounting from Top

Preload Class

Very Light Preload, Very Light Preload (0 ~ 0.02C), Z0

Precision Code

C, Normal

Material

Carbon Steel
