Important Details
- Application Considerations:ย High Holding Force, Low Backlash, Zero Maintenance, NexSafe Certified Safety Product
- Can Be Used For Infrequent Emergency Stops
- For Other Guide Rail Manufacturers Or Guide Rail Series Click HERE.
Have a questionย about a product or application?
Specifications
- Weight: 4.8 lbs
- Engagement Method: Spring
- Release Method: Air
- Backlash: < 0.20 mm
- Open Or Enclosed Design: Open
- Primary Finish: Black Oxide
- Static b10/b10d Cycle Life: 2000000/4000000
- Min Ambient Temp.: 40 ยฐF
- Max Ambient Temp.: 150 ยฐF
- Max Intermittent Ambient Temp.: 212 ยฐF
- CE Certified: CE
- RoHS Compliant: RoHS
- Approx. Engagement Response Time: 70 ms
- Product Weight: 1.54 kg
- Max Operating Pressure: 6.9 bar
- Min Release Pressure: 5.5 bar
- Air Chamber Volume: 13.400 cmยณ
- Inlet Size: 4 mm, Plastic Tubing Fitting Screwed Into A M6 Port
- Manufacturer: HIWIN
- Series: HG
- Size: 30
- Linear Holding Force: 1170 N
- Safety Rating: NexSafe Certified
- Materials Of Construction: Black Oxide
Dimensions
- Length: 100.0 mm
Notes
- Product Features: Safety Rated, Spring Engaged, Air Released
- Restrictions: Suitable For Infrequent E-Stops, Not For Use In Cyclic Dynamic Braking Applications
